Standard: Conforms to EN 795 Class-B

Quick Info

• Wheel-mounted for horizontal mobility
• Dual-beam grip adjustment prevents twisting and turning
• Material: Aluminium Alloy
• Fixing Range : 75mm to 300mm


INDUSTRY

Construction
Telecommunication
Steel Industries

IDEAL APPLICATIONS

Creating Temporary
Anchorage
Road & Bridge Conts
SPECIAL FEATURES
FALL ARREST
STRONG

FIXING RANGE

Beam size from 75 mm to 300 mm

MECHANICAL CHARACTERISTICS
High-strength Aluminum Alloy
Breaking Force - Less than 6 kN
Breaking Strength - 25 kN
Weight - 3.535 kg
Safe Working Load Limit 200 kg
Temp. Range - −30°C to 50°C

TEST COMPLIANCE - DYNAMIC STRENGTH
When subjected to a fall with a rigid mass of 100 kg.,
the breaking force is less than 6 kN

PHYSICAL PARAMETERS

Robust & durable casing made from high impact
aluminum alloy

Integral D-ring provides an anchorage connection point
for shock absorbing and self-retracting lanyards

FEATURES
Wheel mounted for horizontal mobility
Attachable anywhere and glides effortlessly along
the beam and provides horizontal mobility
Dual beam grip adjustment prevents twisting and turning
Conforms to EN 795 - Class-B

MARKINGS
Manufacturers Logo, details & mailing address
Model No., Batch No., Serial No.
Year of Manufacturing

Material
Approvals & CE

STORAGE
Store the beam roller in a dry area away from
ultra violet rays & moisture

Do not store in direct/ high heat or sunlight as
this may distort the Colour
